Highlight:
                                    SMT stencil fiber laser cutter, sheet metal laser cutting machine, SMT laser cutting machine with warranty


SMT Sheet Metal Stencil Fiber Laser Cutting Machine

1.Unique waste collection structure
Based on the new structure design, YS-SL6060 uses innovative waste and smoke collection system, which completely frees customers from "equipment stabilization killers" such as chips, slag, iron dust and so on. It greatly improves the service life and stability of the equipment.

2.High Power Fiber Laser
YS-SL6060 is a semiconductor-pumped solid-state high-power fiber laser with advanced technology. Increasing the cutting efficiency also greatly increases the types of Machinable products. It is easy to deal with both ordinary metal sheets and precise parts with a certain thickness.

3.Provide users with specialized process solutions
Professional fixture design, can adapt to a variety of sizes, shapes of materials, so that every minute of production belongs to laser cutting. This is not only a device, but also a set of equipment process system that can optimize the user's process and give full play to the maximum value of the equipment.

Technicals	Parameters
Model	YS-G680
Cutting speed	Ordinary：15000pads/h~~~Hig：24000pads/h
Cutting area	680mm*680mm
Cutting thickness	0.02mm~0.5mm
Positioning accuracy	±0.002mm
Repeat positioning accuracy	±0.002mm
Efficiency	100W
Operation software	SuperCut-AL
Machine size	1500mm(L)1600mm(W)1500mm(H)
Maximum size of clamping net frame	780mm1500mm40mm
Maximum clamping steel sheet size	820mm*700mm
Max length of cutting stencil	1500MM
Focused spot diameter	20±5um
Laser source	FibeLaser
Beam quality	M2＜1.1
Laser Wavelength	1090nm
Ambient temperature	20±2℃
Ambient humidity	＜60%
Soft-hard wares	Include one set of PC and CAM software
Compatible file	Gerber,DXF
Power	Single phase 220V/3KW，50/60HZ.10A
Auxiliary gas	Industrial Oxygen-Compressed Air
Air press	8~12bar
Machine body	marble
Machine weight	3000KG
