Name: DIP On-line Dual Side AOI Inspection Optical System Machine
Brand: YUSH Electronic Technology Co.,Ltd
SKU: YS- AI-5146W
Price: 70000 USD
Availability: InStock

Product Details

Place of Origin: Guangdong

Brand Name: YUSH

Model Number: YS- AI-5146W

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD70000

Delivery Time: 20work days

Payment Terms: L/C,D/A,D/P,T/T,Western Union

Supply Ability: 1000

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                            DIP AOI inspection machine, dual side optical inspection system, automatic optical inspection machine


Power:	AC220 50/60Hz,5A	Rated Power:	520W
PCB Weight:	Max:10Kg	PCB Edge:	3.0mm
Inspection Speed:	0.23sec/FOV	Weight:	890Kg
Showroom Location:	None

Power:	AC220 50/60Hz,5A
Rated Power:	520W
PCB Weight:	Max:10Kg
PCB Edge:	3.0mm
Inspection Speed:	0.23sec/FOV
Weight:	890Kg
Showroom Location:	None

DIP On-line Dual Side AOI Inspection Optical System Machine

Features

On-line DIP dual side AOI for plug-in after soldering.
High inspection rate and low false alarm rate, automatically check color ring resistor, capacitor, diode, socket, etc.
Defect type: wrong part, missing part, reverse polarity and other defects of DIP element.
Spanning erection without change of production line.
Simplified programming flow, very simple interface. Support batch modifying parameters with one-key.
Centralized control. Interconnection between multiple equipment.
Real-time inspection without stopping the board.
Easy to move, adjustable height and width.
Locate defects quickly and can control production line.
PCBA dimensions: Maximum 400*300mm (12MP) / Maximum 520*380mm (31MP) Multiple selectable options.
Data is traceable. Support SPC alarm, LOG automatic collecting and storage function, NG warning/alarm function, Remote programming & debugging.

Advantages

Deep Learning Algorithm

YS AOI by applying deep learning algorithm, big data optimization and intelligent minimalist programming in industrial inspection, YS enables intelligent judgment by one-click automatic identification of components and solder joints, thus addressing the two major pain points of traditional algorithms, namely, long programming time and high false alarm rate.

Quick Inspection Speed

YS AOI Genetic algorithm path planning
Less number of FOV, Intelligently skip positions without welds. Reduce number of FOV and enhance efficiency
Photographing path is shorter. Reduce large-span FOV skipping to further save time.
More suitable imaging position, Avoid solder joint at FOV joint to guarantee test results.
GPU image parallel processing, Faster data running speed.

MES System Data Report

Camera automatically reads code (bar code and QR code).
Complete data, including overall statistic data and all inspection information of each board inspected.
Support one-key export, which is convenient for traceback. Data can be effectively applied in MES system.

Specifications

Model	YS DIP On-line Dual side AOI AI-5146W (After THT Soldering)	YS DIP On-line Dual side AOI AI-5146WL (After THT Soldering)
FOV	52.6*44mm
Resolution	21.5um
Camera	5M
Inspection Speed	0.23sec/FOV
PCB Height	Top:75mm, Bottom:75mm
PCB Thickness	0.3 ~ 6.0mm
PCB Edge	3.0mm
PCB Warpage	±3.0mm
PCB Weight	Max:10Kg
Conveyor Height	750&900±20mm
With Adjustment	Manual&Auto
Conveyor Direction	L ~R or R ~L
Power	AC220 50/60Hz,5A
Rated power	520W
Communication	SMEMA
Weight	890Kg	100Kg
Dimension	L1050W1335H1650mm	L1050W1535H1650mm
